Gripstrut Safety Grating

FASTENING SYSTEMS FOR SAFETY GRATINGS

GRIP STRUT® exceeds Federal Specification RRG-1602-Latest Revision. Multi-directional tests were performed under five conditions - dry, greasy, muddy, soapy and icy - with results proving up to 180% more slip-resistance than other similar products. The serrated surface of GRIP STRUT ® provides for slip resistance in all directions, under all conditions! And with 4-1/2" side channels on GRIP STRUT® walkway platforms, OSHA requirement for toeboards on elevated structures is also satisfied.

The open design of GRIP STRUT® minimizes maintenance, permitting quick drainage of fluids, chips, grease and mud, and ice accumulation shears easily under normal foot pressure.

High strength-to-weight performance is achieved through depth of section and structural design. The one piece construction offers integral side channels that form a plank that can support loads with minimum traverse and longitudinal deflection.

Regular GRIP STRUT® is available in a multitude of options to accommodate your needs for ladder rungs, stair treads, platforms and elevated walkway systems:

• Widths from 1-5/8" to 24"

• Depths from 1-1/8" to 4-1/2"

• Lengths up to 24'

• 12 and 14 gauge steel (mill galvanized, black HRPO), .080" and .100" aluminum, and 16 gauge stainless steel are standard finishes
  Ladder rung, plank and walkway configurations.
